HIMA Z7116 Power Supply & Monitoring Module | HIQuad Safety Component

Manufacturer: HIMA
Product No.: Z7116
Condition：in Stock
Product Type: Power Supply & Monitoring Module
Product Origin: Germany
Payment:T/T, Western Union
Weight: 600g
Shipping port: Shanghai/Yiwu/Shenzhen
Warranty: 12 months

Quantity

Product Description

Overview

The HIMA Z7116 is a dedicated power supply and monitoring module for the HIQuad, H41q, and H51q safety systems. It provides a stabilized 24 VDC power source to the subrack, delivering precise voltage regulation and monitoring to critical CPUs and I/O modules. Its integration ensures that safety-related logic operates within strict tolerances, preserving system integrity and reliability in industrial environments.

Designed for demanding applications, the Z7116 combines voltage stabilization, overcurrent protection, and diagnostic feedback, making it essential for SIL 3-rated safety systems.

Key Features

Provides regulated 24 VDC power to subrack bus and modules
Monitors voltage levels and reports power status to the CPU
Includes overcurrent protection to safeguard system components
LED indicators display input and output status for maintenance convenience
Front-panel test points allow safe voltage measurement without disconnection
Supports redundant configurations for high-availability systems
EMC shielding protects against electromagnetic interference
Built to endure industrial vibration, shock, and harsh environmental conditions

Technical Specifications

Feature	Specification
Model Number	Z7116 / 3236
Module Type	Power Supply & Monitoring Module
Input Voltage	24 VDC (operating range 18–30 VDC)
Output Voltage	24 VDC stabilized to bus
Current Monitoring	Integrated overcurrent protection
Fusing	Built-in safety fuses
Cable Length	Typically 5 meters (cable plug module)
Connector Type	EN 175301-803 compliant
Input Signal	1-signal, 6 mA including cable plug
Switching Time	8 ms typical
Power Consumption	5 VDC / 120 mA; 24 VDC / 200 mA
Space Requirement	4 TE (DIN slot width)
Operating Temperature	-25°C to +70°C
Weight	0.60 kg
Mounting	Standard H41q/H51q subrack slot

Applications

The Z7116 is used in safety-critical industrial installations including oil & gas facilities, chemical plants, and energy production. It ensures reliable power distribution and monitoring to prevent voltage dips or transients from triggering unexpected CPU faults or system errors.

FAQ

Q: Can the Z7116 operate in redundant configurations?
A: Yes, multiple modules can be installed in parallel to maintain power continuity even if one unit fails.

Q: Does the module require maintenance?
A: No routine maintenance is required. Status LEDs and monitoring contacts allow easy verification of proper operation.

Q: What environments is it suitable for?
A: It is designed to withstand vibration, shock, temperature extremes (-25°C to +70°C), and EMI conditions typical of industrial settings.

Similar Models

HIMA Z7115: Standard power module without monitoring contact
HIMA Z7117: Enhanced redundancy support and higher current capacity
