6ES7322-1BH01-0AA0 | Siemens | Simatic S7-300, Digital Output SM 322

Overview

The 6ES7322-1BH01-0AA0 is a SIMATIC S7-300 digital output module (SM 322) designed for reliable DC output control in industrial automation. It provides 16 channels and ensures safe operation with high-voltage isolation.

Key Features

• 16 digital outputs for precise control of actuators and devices.

• Rated load voltage: 24 V DC with typical power loss of 4.9 W.

• High isolation tested up to 500 V DC for safe industrial operation.

• Compact dimensions allow easy installation in S7-300 racks.

• Lightweight design ensures space-efficient system integration.

Technical Specifications

• Manufacturer: Siemens

• Part Number: 6ES7322-1BH01-0AA0

• Product Type: SIMATIC S7-300 Digital Output SM 322

• Load Voltage L+: 24 V DC

• Power Loss: 4.9 W (typical)

• Number of Outputs: 16

• Isolation Tested With: 500 V DC

• Dimensions: 12 × 4 × 12.5 cm

• Weight: 0.19 Kg

• Shipping Weight: 3 Kg

Applications

The 6ES7322-1BH01-0AA0 is ideal for S7-300 PLC systems, industrial automation, and process control applications. It provides reliable digital output for controlling valves, relays, and other actuators.
