6ES7332-5HF00-0AB0 | Siemens | SIMATIC S7-300 Analog Output SM 332

Overview

The 6ES7332-5HF00-0AB0 is a SIMATIC S7-300 analog output module (SM 332) designed for precise process control. It provides reliable 8-channel analog output and supports high-voltage isolation for industrial automation applications.

Key Features

• 8 analog outputs for accurate control of actuators and devices.

• Rated voltage: 24 V DC with low typical power loss of 6 W.

• Supports cable lengths up to 200 m with shielded connections.

• Isolation tested up to 500 V DC for safe operation.

• Requires 40-pin front connector for easy integration.

Technical Specifications

• Manufacturer: Siemens

• Part Number: 6ES7332-5HF00-0AB0

• Product Type: SIMATIC S7-300 Analog Output SM 332

• Rated Value: 24 V DC

• Power Loss: 6 W (typical)

• Number of Analog Outputs: 8

• Maximum Shielded Cable Length: 200 m

• Isolation Tested With: 500 V DC

• Required Front Connector: 40-pin

• Dimensions: 11.7 × 4 × 12.5 cm

• Weight: 0.272 Kg

• Shipping Weight: 1.5 Kg

Applications

The 6ES7332-5HF00-0AB0 is ideal for S7-300 automation systems, industrial process control, and analog signal applications. It ensures precise control of valves, motors, and other analog devices.
