ABB 3BHE016011R0006 UNS0118A-Z Control Module

Technical Overview

The UNS0118A-Z (3BHE016011R0002) is a specialized control unit engineered by ABB for precision processing within industrial automation systems. This module utilizes an advanced microprocessor architecture to handle complex logic sequences and real-time data acquisition. Designed specifically for high-reliability environments, it ensures stable performance in applications requiring rigorous timing and synchronization.

Detailed Technical Specifications

The following data outlines the mechanical and electrical characteristics of the UNS0118A-Z (3BHE016011R0002):

• Logic Processing: Integrated high-speed microprocessor for reduced cycle times.

• Input Voltage: 24 V DC (Nominal).

• Operating Current: Standard industrial logic levels.

• Communication Protocols: Multi-interface support for seamless system integration.

• Chassis Construction: Robust industrial-grade casing for EMI/RFI shielding.

• Physical Footprint:

• Length: 250 mm

• Width: 150 mm

• Height: 50 mm

• Net Weight: 0.5 kg

• Thermal Tolerance:

• Operational Range: -25°C to +70°C

• Storage Range: -40°C to +85°C

• Relative Humidity: 5% to 95% non-condensing.

Functional Application

The UNS0118A-Z (3BHE016011R0002) is primarily deployed in excitation systems, power conversion units, and large-scale motor control centers. Its ability to withstand extreme temperature fluctuations makes it ideal for heavy industrial sectors such as power generation, metallurgy, and marine engineering.
