ABB HENF209698R1 P4LTb RF-Converter Module

Specifications and Model Data

Model/Part Number : P4LBA HENF209698R1
Product Type : P4LTb RF-Converter Module
Application System : ETL600 Digital Power Line Carrier System

Key Features

• Converts low-frequency signals into radio frequency (RF) signals for secure and efficient communication over power lines.

• Core component in power line communication (PLC) systems.

Interfaces

• Voltage input : 1 × V.11, 2 × V.24

• Data interface :

• 4 × RS-232 (V.24/V)

• Sub-D 15-pin (V.11)

• Sub-D 9-pin (HMI)

• IRIG-B port

• Data transfer rate : 50 to 9,600 bps (narrowband)

• Indicator lights :

• RDY (green)

• P4LT (red)

• SYS (red)

• Power supply : DC-powered

• Weight : Approx. 105 g

Application Scenario

The P4LBA module is primarily used in the power industry for power line communication (PLC).
This technology utilizes existing high-voltage transmission lines as a communication medium to transmit voice, data, control signals, and protection signals.
As a key component, the P4LBA module ensures stable data transmission on power lines, which is crucial for remote monitoring, data collection, and fault protection of power systems.
