ABB PFCA 401S | 3BSE024387R2 Tension Control Unit

Product Description

Overview

The ABB PFCA 401S (3BSE024387R2) is a precision control unit designed for tension monitoring in industrial processes. As part of the PillowBlock Tension Measurement System, it converts load cell millivolt signals into standardized analog outputs. The “S” variant supports a single-channel configuration, accommodating two load cells to measure one web tension line. This module ensures accurate tension control in high-speed operations such as paper mills, steel rolling, and converting lines.

Technical Features

High-Accuracy Signal Processing

• Advanced filtering electronics reduce noise and vibration effects

• High linearity and repeatability for consistent tension measurements

• Rapid response time supports real-time tension adjustments

Calibration and Setup

• Digital configuration for load cell parameters including sensitivity, wrap angle, and tare weight

• Auto-Zero function compensates for roller weight and mechanical misalignment

Connectivity and Outputs

• Multiple analog outputs (0–10V, 0–20mA, 4–20mA) for total or individual side tension

• Optional front-panel display for local monitoring in N, kg, or lb

Durability and Reliability

• Rugged enclosure for EMC resistance and temperature variation tolerance

• Continuous self-diagnostics for load cell health, short-circuit detection, or hardware faults

Technical Specifications

Typical Applications

• Paper and board mills for constant web tension

• Steel processing lines including cold rolling and pickling

• Converting processes such as laminating, printing, and coating where precise material tension is critical

FAQ

Q: How many load cells can the PFCA 401S support?
A: It supports two load cells for a single tension measurement channel.

Q: Can the outputs be configured for both voltage and current simultaneously?
A: Yes, the module can provide multiple analog output formats to interface with PLCs or DCS systems.

Q: What is the recommended procedure when replacing a unit?
A: Backup all calibration parameters including wrap angles and load cell sensitivity to ensure accurate continuity.
