ABB SPDSI14 SAFEmove™ Dual-Channel Safety Input Module

Manufacturer: ABB
Product No.: SPDSI14
Condition：in Stock
Product Type: Digital Input Module
Product Origin: Switzerland
Payment:T/T, Western Union
Weight: 1000g
Shipping port: Shanghai/Yiwu/Shenzhen
Warranty: 12 months

Quantity

Product Description

Overview

The ABB SPDSI14 is a high-reliability dual-channel programmable safety logic module in the SAFEmove™ system. Designed for SIL 3 / PLe certified applications, it provides advanced safety interlocking for industrial machinery. It supports up to 14 safety inputs and is ideal for emergency stops, light curtains, safety gates, and other critical protection functions in high-risk environments such as injection molding and stamping machines.

Technical Specifications

Feature	Specification
Model / Order Number	SPDSI14
Module Type	Dual-Channel Programmable Safety Logic Module
Series	ABB SAFEmove™
Safety Certification	SIL 3 (IEC 61508), PLe (ISO 13849), EN 60204-1
Input Channels	14 (8 dual-channel + 6 configurable single-channel)
Input Voltage	24 VDC (PNP/NPN compatible), leakage ≤ 1.5 mA
Safety Outputs	3 × Semiconductor outputs (0.5 A @ 24 VDC), 2 × Relay outputs (8 A @ 250 VAC)
Response Time	≤ 15 ms for emergency stop signals
Power Supply	24 VDC (±20%), ≤ 5 W
Environment	-25°C to +55°C, 95% RH non-condensing, vibration 5 g (10–150 Hz)
EMC Immunity	±2 kV EFT, ±4 kV surge, EN 61326-1 compliant
Electrical Life	Relay outputs: 100,000 cycles at rated load
Connection Type	Spring clamp terminals (0.2–2.5 mm² wire)
Programming Tool	SafeMove Builder 3.1
Compatibility	SPDSA-01 Input Expansion, SPDSO-08 Safety Output, ABB AC500 PLC

Core Features

Programmable Safety Logic: Supports 32 predefined safety function blocks, including interlocks, enable, and delay-off functions. Allows up to 8 cascading logic layers.
Dual-Channel Input Flexibility: Compatible with type 0, 1, or 2 safety devices, including emergency stops, safety gates, and light curtains.
Real-Time Diagnostics: Red, yellow, and green LEDs for each channel; Modbus RTU over RS-485 for remote diagnostic reporting.
Cross-Check Processing: Dual-processor comparison ensures fault tolerance and output loop monitoring.
Tool-Free Configuration: Configure basic safety logic directly on the module panel; six programmable function keys allow custom safety macros.
Integration Support: Supports PROFIsafe/CIP Safety via optional SP-01 communication module, fully compatible with ABB AC500 PLC safety architecture.
Visualization & Connectivity: Five-digit 7-segment display for status codes; Bluetooth connection allows mobile monitoring.

Applications

Automotive Manufacturing: Light curtain interlocks for welding robots, dual-hand control for stamping lines.
Rubber & Plastic Machinery: Safety gate hydraulic lock for injection molding, intrusion detection in vulcanization areas.
Packaging & Logistics: Robotic arm movement limits, emergency stop chains on conveyors.
Metalworking: CNC machine tool guard interlocks, high-risk equipment protection.

FAQ

Q: How many safety inputs can the SPDSI14 handle?
A: It supports 14 inputs, including 8 dual-channel and 6 configurable single-channel inputs.

Q: Can I configure safety logic without software?
A: Yes, basic safety logic can be programmed directly on the module using panel buttons.

Q: What safety certifications does it meet?
A: SIL 3 (IEC 61508), PLe (ISO 13849), and EN 60204-1.

Q: Can it communicate with other systems?
A: Yes, it supports PROFIsafe and CIP Safety with optional communication cards and is compatible with ABB AC500 PLC safety systems.
