ABB XFD213A 3BHE028122R0001 Switching Actuator with Inputs

ABB XFD213A Switching Actuator with Inputs

Product Number: 3BHE028122R0001
Function: KNX device for home and building automation, with 4 outputs and 8 inputs.

Specifications

Outputs

• Quantity: 4

• Type: Each output with 2 relays (for up/down control)

• Rated Voltage: Max 230 V AC, 50/60 Hz

• Rated Current: Max 6 A

Inputs

• Quantity: 8

• Scanning Voltage: 35 V pulsed

• Scanning Current: 0.1 mA

Power

• Operating Voltage: 21–30 V DC (via KNX bus)

• Power Consumption (KNX): < 250 mW (when outputs are off)

Connections

• Outputs/Inputs: Screw terminals (0.2 to 4 mm² cable)

• KNX: Screwless bus connection terminal

Mechanical & Installation

• Protection Class: IP20 (EN 60529)

• Installation: 35 mm DIN mounting rail (EN 60715)

• Dimensions: 6 space units (105 mm wide)

• Housing: Halogen-free plastic, V-0 flammability rating (UL94)
