Allen Bradley 1606XL480EP

Product Overview

The 1606-XL480EP (1606-XL480EP) is a high-efficiency, industrial-grade power supply from Allen-Bradley’s Essential series. Designed to provide a stable 24VDC output for PLC systems, sensors, and actuators, this unit is engineered for heavy-duty automation environments. It features a versatile wide-range input, allowing it to operate on standard AC line voltages or high-voltage DC sources. With a continuous output of 20A and a significant short-term power reserve (up to 30A), it is perfectly suited for handling the high inrush currents typically associated with motor starts and large inductive loads.

Technical Specifications

• Manufacturer Allen-Bradley / Rockwell Automation

• Model / Catalog No. 1606-XL480EP

• Series Series B (Essential Line)

• Product Type Switch-Mode Power Supply (SMPS)

• AC Input Range 100–120V / 200–240V AC (Auto-select/Wide range)

• DC Input Range 110–150V DC

• Nominal Output Voltage 24V DC (Adjustable 24–28V DC)

• Continuous Current 20A @ 24V | 17A @ 28V

• Power Reserve (4 sec) 30A @ 24V | 26A @ 28V

• Total Power Output 480W (Continuous)

• Efficiency High-efficiency design with low heat dissipation

• Mounting Standard DIN Rail

• Unit Weight 1.4 kg (3.1 lbs)

• Condition Factory New in Original Packaging

Performance & Reliability

The 1606-XL480EP (1606-XL480EP) is built to maintain system uptime in rigorous industrial settings:

• Short-Term Overload Capability The 4-second power boost (30A) allows the system to overcome temporary peak demands without voltage drops or shutdowns.

• Flexible Input Options Supports both global AC standards and DC battery-backed systems, making it a versatile choice for international projects.

• Compact Thermal Management Despite its 480W capacity, the unit maintains a slim profile to save valuable DIN rail space while ensuring efficient cooling.

• Ruggedized Construction Specifically designed to resist the vibration and electrical noise common in motor control centers and machine tool applications.
