The Bently Nevada 102045-040-01, also cataloged as the 102045 4 Meter Armored Cable, operates as a dedicated hardware component for signal transmission between proximity probes and Proximitor Sensors within the 3300 XL 8 mm Proximity Transducer System. The armored cable provides a shielded electrical path for vibration, displacement, and shaft position measurement signals.

Hardware Specifications

Eddy-Current Signal Transmission and Cable Integrity

The 102045-040-01 armored extension cable is designed for connection between a 3300 XL 8 mm proximity probe and a Proximitor Sensor. The cable maintains transmission of eddy-current measurement signals used for vibration, displacement, and shaft position monitoring.

The shielded armored construction provides mechanical protection against vibration, abrasion, and oil exposure in rotating machinery environments. The cable electrical characteristics, including 50 Ohm characteristic impedance and controlled propagation velocity, support stable proximity measurement signal transfer.

The cable configuration supports Bently Nevada proximity monitoring systems requiring consistent signal transmission between sensing elements and signal conditioning hardware.

Frequently Asked Questions (FAQ)

Q: What system is the 102045-040-01 extension cable designed for?
A: The cable is designed for use with the Bently Nevada 3300 XL 8 mm Proximity Transducer System.

Q: What is the rated voltage of the 102045-040-01 cable?
A: The cable has a voltage rating of 300 V rms.

Q: What protection features are provided by the cable construction?
A: The armored construction provides mechanical protection against vibration, abrasion, and oil exposure while maintaining shielded signal transmission.

Field Installation Guidelines

Install the armored extension cable with appropriate mechanical support to prevent excessive pulling force, sharp bending, or abrasion damage. Route the cable separately from high-current power wiring and switching sources that may introduce electrical interference.

Maintain connector cleanliness and ensure secure connections between the proximity probe and Proximitor Sensor interfaces. Verify cable continuity, shielding integrity, and signal path performance before commissioning the monitoring system.

Avoid installation conditions that exceed the specified temperature range or expose the cable to mechanical conditions beyond its armored protection capability.
