Bently Nevada 133811-02 3500/61 Temperature Monitor

Product Description

The 51130481-100 (MC-TAMR03) is a high-density Remote Termination Assembly (RTA) designed for the Honeywell TDC 3000 and Experion PKS control systems. This module provides a specialized interface for low-level field signals, offering precise conditioning for Resistance Temperature Detectors (RTD) and a wide array of industrial thermocouples.

Built for the rigors of heavy industrial processing, the 51130481-100 ensures accurate data acquisition by utilizing high-impedance inputs that minimize signal degradation over long cable runs. Each channel is equipped with an independent recorder output, allowing for parallel monitoring without disrupting the primary control loop. Its robust protection circuitry and FCC-compliant shielding make it an essential component for stable temperature management in refineries, power plants, and chemical facilities.

Technical Specifications

• Input Sensor Compatibility:

• RTD: Platinum or Nickel sensors ranging from -200°C to +850°C.

• Thermocouples: Full support for Types E, J, K, T, C, R, S, and B (-200°C to +1500°C).

• Measurement Precision: * General Accuracy: 0.25% of full-scale range.

• Digital Resolution: 1°C increments.

• Input Impedance: Greater than 10 MΩ per lead to ensure signal purity.

• Channel Configuration: One dedicated recorder output per individual channel.

• Alarm Management: Supports dual-stage (Over/Under) alarms, adjustable from 0% to 100% of the full-scale span.

• Integrated Protection: * Reverse polarity protection.

• Overvoltage surge suppression.

• Continuous short-circuit protection.

• Operating Environment:

• Standard I/O Modules: -30°C to +65°C.

• Internal Barrier I/O: 0°C to +65°C.

• Compliance: FCC Part 15 (EMI/RFI protection).

• Physical Profile: 241.3 mm (H) x 24.4 mm (W) x 241.8 mm (D).

• Net Weight: 0.91 kg (910g).

• Origin: USA.

Application Scenarios

The 51130481-100 is ideally suited for high-stakes thermal monitoring, such as:

• Boiler Tube Temperature: Monitoring high-temperature thermocouple strings in steam generation.

• Distillation Columns: Precise RTD-based temperature gradient tracking in petrochemical refining.

• Furnace Control: Reliable measurement for Type R/S/B sensors in glass or metal manufacturing.
