Bently Nevada 136180-01 | 3500 Series MPU & Comm Gateway Module

Product Overview

The Bently Nevada 136180-01 is a dual-function solution encompassing a Magnetic Pickup (MPU) Speed Sensor and a 3500/92 Communication Gateway Module. Designed for critical machinery monitoring and industrial network integration, it provides reliable RPM measurement and data communication for the 3500 Series monitoring systems.

The Magnetic Pickup delivers accurate rotational speed signals without requiring external power, while the Communication Gateway enables seamless connectivity between 3500 Series I/O modules and Ethernet networks, ensuring efficient real-time system monitoring and control.

Product Description

Magnetic Pickup (MPU) Sensor

The 136180-01 MPU is a passive, self-generating sensor used to detect the rotation of shafts by sensing ferrous gear teeth or similar discontinuities. It produces an AC voltage proportional to shaft speed, providing input for tachometer and overspeed protection systems. The stainless steel construction and hermetically sealed design allow operation in extreme temperatures and harsh industrial conditions.

3500/92 Communication Gateway Module

This module serves as a network interface for 3500 Series I/O modules. It features a standard RJ45 connector and supports 10 Mbps communication for real-time monitoring. Optimized for low power consumption (5–5.6 W) and a wide operating range (-30°C to 65°C), it ensures reliable integration of multiple sensors and control points into centralized industrial networks.

Key Features

Magnetic Pickup Sensor

• Self-generating electromagnetic design with no external power required.

• High sensitivity across a broad RPM range.

• Stainless steel housing resistant to oil, moisture, and chemical exposure.

• Hermetically sealed with high-vibration tolerance.

• Operating temperature: -54°C to +120°C (-65°F to +250°F).

3500/92 Communication Module

• Connects 3500 Series I/O to Ethernet networks via RJ45.

• Stable 10 Mbps data link for real-time monitoring.

• Low power operation at 5–5.6 W.

• Designed for temperatures from -30°C to 65°C.

• Compact, robust module suitable for harsh industrial environments.

Technical Specifications Table

Applications

• Machinery rotational speed measurement for turbines, compressors, and generators.

• Overspeed detection and diagnostic monitoring via 3500/50 Tachometer modules.

• Industrial network integration for 3500 Series I/O modules with real-time data acquisition.

• Remote monitoring setups in oil & gas, power generation, and heavy industrial systems.

FAQ

Q1: Does the MPU require external power?
A1: No, the Magnetic Pickup is passive and self-generating, producing AC voltage proportional to shaft speed.

Q2: What air gap is recommended for optimal signal?
A2: Smaller air gaps increase signal strength, but maintain safe clearance to prevent gear contact.

Q3: Can the gateway module handle multiple sensors simultaneously?
A3: Yes, it aggregates data from connected 3500 Series I/O modules and transmits over Ethernet.

Q4: Are both modules suitable for extreme temperatures?
A4: Yes, the MPU handles -54°C to +120°C, and the gateway module operates from -30°C to 65°C.
