Bently Nevada 140734-03 Aeroderivitive Gt Vibration Monitor

Manufacturer: Bently Nevada
Product No.: 140734-03
Condition：in Stock
Product Type: Aeroderivitive Gt Vibration Monitor
Product Origin: USA
Payment:T/T, Western Union
Weight: 1000g
Shipping port: Shanghai/Yiwu/Shenzhen
Warranty: 12 months

Quantity

Brand: Bently Nevada

Condition: 100% New Original

Payment Terms: T/T

Minimum Order Quantity: 1pc

Product Description: Bently Nevada 140734-03 Aeroderivitive Gt Vibration Monitor

The Bently Nevada 3500/44M Aeroderivative GT Vibration Monitor is a four-channel monitor designed specifically for Aeroderivative Gas Turbine applications. It supports input from two separate Keyphasor signals, enabling each channel pair to use a different tracking filter.

Specifications

Model: 3500/44M Aeroderivative GT Vibration Monitor
Inputs:
- Accepts 1 to 4 signals from interface modules, velocity monitors, and accelerometers.
- Two separate Keyphasor signals for each channel pair.
Power Consumption:
- 7.7 watts (typical)
Input Impedance:
- Greater than 95 kΩ for Proximitor and acceleration inputs
Sensitivity:
- 3.94 mV/(mm/s) or 5.71 mV/(mm/s)
Outputs:
- Buffered transducer outputs with short-circuit protection
Recorder Output:
- +4 to +20 mA proportional to monitor full-scale
Update Rate:
- 100 ms or less
