Bently Nevada 200200-02-02-CN | 3300 XL Proximitor Sensor | Vibration Measurement

Overview

The Bently Nevada 200200-02-02-CN is a 3300 XL Proximitor Sensor, designed for precise vibration, position, and speed monitoring in rotating machinery. This sensor is an essential component of the 3300 XL 8mm Proximity Transducer System, using eddy current technology to measure the distance between the probe and a target, typically a rotating shaft. It is widely used in industries that require accurate condition monitoring and machinery health assessment.

Key Features and Specifications

• Output Signal: Linear voltage signal proportional to the distance between the sensor probe and the target.

• Scale Factor: 7.87 V/mm (200 mV/mil) for a standard AISI 4140 steel target.

• Operating Voltage: Requires a nominal input of -24 VDC.

• Linear Measurement Range: 2.0 mm (80 mils), with measurement capability starting from approximately 0.25 mm (10 mils) from the probe tip.

• Operating Temperature: Designed to function in extreme environments with an operating range of -52°C to +100°C (-62°F to +212°F).

• Construction Material: The housing is made from A380 Aluminum, offering durability and resistance to wear and tear.

• Connector Type: Features gold-plated brass ClickLoc connectors, designed to resist loosening under vibration conditions.

Mounting & Certification

• Mounting Option: Panel mount configuration, providing secure and stable installation in a variety of setups.

• Certification: China Ex certification for explosion-proof and intrinsic safety, ensuring suitability for hazardous environments.

Applications

The 3300 XL Proximitor Sensor is commonly used for:

• Monitoring vibration and position in rotating machinery.

• Speed measurement in turbine and motor systems.

• Condition-based monitoring for critical industrial machinery.

FAQ

Q: What is the typical application of this sensor?
A: The sensor is ideal for condition monitoring in rotating machinery, including turbines, compressors, and motors. It helps detect misalignment, imbalance, and other faults.

Q: Can this sensor be used in hazardous environments?
A: Yes, the 200200-02-02-CN sensor is certified for use in explosive atmospheres with its China Ex certification, making it safe for use in hazardous locations.

Q: What type of material can the probe measure?
A: The sensor works with standard AISI 4140 steel targets, offering a reliable and consistent scale factor for most industrial applications.
