The Bently Nevada 3300/16-15-01-01-00-00-01, also cataloged as the 3300/16 Dual Vibration XY/GAP Monitor Module, operates as a dedicated hardware component for radial vibration and shaft position monitoring within Bently Nevada 3300 Machinery Protection System platforms.

Suffix Breakdown & Model Matrix

Hardware Specifications

Mechanical Monitoring & TSI Integration

The 3300/16 module processes inputs from accelerometers and velocity transducers to support complex rotor dynamics monitoring. It is essential for maintaining accurate signal paths, requiring rigorous gap voltage validation when connected to proximity-based systems to ensure linear transducer output. The module incorporates cross-talk suppression between its dual channels to maintain high signal-to-noise ratios during the analysis of shaft centerline behavior, ensuring that vibration data remains shielded from external electromagnetic interference.

Frequently Asked Questions

Q: What is the benefit of the enabled Trip Multiply feature?

A: The Trip Multiply feature allows operators to temporarily increase alarm thresholds during machine start-up, preventing false trips caused by expected transient vibration spikes that occur during ramp-up phases.

Q: Does this module support non-XL proximity sensors?

A: Yes, the 15-option input configuration is specifically optimized to interface with various accelerometer and velocity-based transducer inputs, supporting specialized monitoring configurations.

Field Installation Guidelines

• Slot Mounting: Insert the module into the 3300 rack and ensure full engagement with the backplane connectors to maintain system power and communication.
• Transducer Wiring: Connect acceleration or velocity transducers using shielded cabling to minimize noise. Ensure the shield is grounded at the instrument rack to protect the low-level signal integrity.
• Trip Configuration: Verify that the Trip Multiply switch or remote trigger is correctly wired to the control system to ensure the suppression function engages only during the required start-up window.
• Validation: Use the front-panel test terminals to confirm signal output stability before finalizing the alarm logic settings in the monitoring software.
