The Bently Nevada 9200-03-02-02-00, also cataloged as the 9200 Two-Wire Velocity Seismoprobe Transducer, operates as a dedicated hardware component for casing vibration velocity measurement within Bently Nevada vibration monitoring systems. The transducer converts mechanical casing movement into electrical output signals for machinery vibration monitoring applications.

Hardware Specifications

Rotor Dynamics and Velocity Signal Processing

The 9200-03-02-02-00 velocity Seismoprobe transducer provides direct casing vibration measurement through electromechanical velocity sensing technology. The device converts mechanical vibration velocity into an electrical signal suitable for processing by compatible Bently Nevada monitoring systems.

The transducer supports rotor dynamics analysis by providing casing vibration data for machinery protection channels, vibration trending, and fault condition evaluation. Its two-wire loop-powered design simplifies field integration by combining signal transmission and power supply through the same electrical connection.

The sensor configuration is designed for integration with Bently Nevada 3300 and 3500 monitoring platforms. Mechanical mounting through the 1/4-28 UNF stud provides fixed coupling between the machine casing and the sensing element for vibration measurement.

Frequently Asked Questions (FAQ)

Q: What vibration parameter does the 9200-03-02-02-00 measure?
A: The transducer measures machine casing vibration velocity and provides an electrical output proportional to the detected mechanical vibration.

Q: How is power supplied to this Seismoprobe transducer?
A: The device uses a two-wire loop-powered configuration and receives operating power from a compatible monitoring system.

Q: What mounting method is used for this model?
A: The transducer uses threaded mounting with a circular base and a 1/4-28 UNF stud connection with side mount connector configuration.

Field Installation Guidelines

Install the Seismoprobe transducer on a rigid machine casing surface using the specified threaded mounting connection. Ensure the mounting location provides direct mechanical coupling to the vibration source and avoids loose structural components.

Route the two-wire signal cable separately from high-current power conductors and switching equipment to reduce electrical interference. Maintain proper cable support and protect the connector area from mechanical stress.

Verify mounting tightness, cable connection integrity, and monitoring channel configuration before commissioning. Confirm signal response through the connected Bently Nevada monitoring system during initial vibration measurement setup.
