Emerson DeltaV S-Series KJ2005X1-BA1 Vertical I/O Carrier 8-Slot

Product Overview

The Emerson KJ2005X1-BA1 is an 8-slot vertical I/O carrier engineered for the DeltaV™ Distributed Control System. Designed as a passive backplane, it provides both physical support and electrical connectivity for DeltaV I/O modules, enabling efficient communication with controllers in redundant or non-redundant configurations. Its vertical format conserves cabinet space while promoting effective heat dissipation through natural convection.

Key Features

High-Density Configuration

• Supports up to 8 I/O modules per carrier for modular expansion

• Vertical mounting minimizes footprint for compact control rooms

Reliable Operation and Redundancy

• Integrated connections for dual 24V DC power buses

• Hot-swappable I/O modules allow replacement without downtime

Fast and Stable Communication

• LocalBus interface ensures low-latency module-to-controller data transfer

• Passive design increases MTBF by eliminating active backplane components

Industrial Strength

• Conformal coating options resist corrosive chemical environments

• Shock- and vibration-resistant design maintains long-term electrical reliability

Technical Specifications

Applications

• Distributed Control Systems requiring compact I/O integration

• Environments with redundant power requirements

• High-density cabinet installations in chemical, petrochemical, and process industries

FAQ

Q: Can this carrier support both redundant and non-redundant modules?
A: Yes, the KJ2005X1-BA1 supports both configurations, ensuring operational flexibility.

Q: Is module replacement possible without shutting down the system?
A: Yes, the carrier supports hot-swappable modules, maintaining continuous operation.

Q: Which termination blocks are recommended?
A: Emerson KJ4001X1-BA2 I/O Termination Blocks are typically used to complete the field wiring interface.

Related Models Comparison

Product Tags

S-Series, Vertical I/O Carrier, 8-Slot, Passive Backplane, Hot-Swappable, Redundant Power
