GE Fanuc|469-P1-HI-A20|Motor

GE Fanuc|469-P1-HI-A20|Motor

  • Manufacturer: GE

  • Product No.: 469-P1-HI-A20

  • Condition：in Stock

  • Product Type: Motor

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 4800g

  • Shipping port: Shanghai/Yiwu/Shenzhen

  • Warranty: 12 months

Product Overview

The GE Fanuc 469-P1-HI-A20 is a sophisticated digital relay belonging to the renowned Multilin™ 469 series. It is engineered to provide comprehensive protection, control, and monitoring for medium and large-sized industrial motors. This relay integrates advanced thermal modeling with precise metering capabilities to ensure the longevity and reliability of critical motor assets.

Designed for versatility, the 469-P1-HI-A20 features a robust drawout case design, allowing for rapid replacement and maintenance without disturbing field wiring. It combines high-speed protection algorithms with extensive communication options, making it a central component in modern industrial automation and power management systems.

Key Features & Benefits

  • Advanced Thermal Protection: Utilizes a dynamic thermal model that accounts for thermal capacity used, negative sequence current (unbalance), and RTD inputs to accurately track motor heating and cooling.

  • Drawout Architecture: The unit is housed in a drawout case, facilitating easy removal and installation for maintenance or replacement, minimizing system downtime.

  • High-Precision Metering: Provides accurate real-time monitoring of current, voltage, and power parameters, with four scalable 4-20 mA analog outputs for integration with external control systems.

  • Comprehensive Fault Recording: Capable of storing waveform data (up to 16 cycles) during trip events, aiding in rapid fault diagnosis and root cause analysis.

  • Flexible Communication: Equipped with RS232 and RS485 ports supporting open protocols (Modbus), allowing for seamless integration into SCADA and DCS networks.

  • Versatile Control Power: Supports a wide range of AC and DC control power inputs, ensuring compatibility with various industrial power distribution schemes.

Technical Specifications

表格

Parameter Specification
Model Number 469-P1-HI-A20
Manufacturer GE Fanuc / GE Multilin
Product Type Motor Management Relay
Origin USA
Phase CT Inputs 1 A Secondaries
Control Power 90-300 V DC / 70-265 V AC (48-62 Hz)
Analog Outputs 4 x 4-20 mA (±1% accuracy, 1200 Ω max load)
Differential CT 1-5000 A Primary (1A/5A Secondary)
Ground CT 1-5000 A Primary (±0.125 A accuracy)
RTD Inputs 12 Inputs (for stator/bearing temperature)
Weight 4.8 kg
Display 40-character Vacuum Fluorescent Display

Protection & Monitoring Capabilities

The 469-P1-HI-A20 offers a suite of protective functions designed to prevent motor damage:

  • Thermal Overload: Mimics the motor's heating characteristics to prevent insulation failure.

  • Stall & Jam Protection: Detects locked rotor conditions during start or run modes.

  • Ground Fault: High-sensitivity detection for insulation breakdown.

  • Phase Unbalance: Protects against negative sequence currents that cause rotor overheating.

  • Short Circuit: Fast-acting trip for high-current faults.
