GE Fanuc IC693PTM101 Power Transformer Module Series 90-30

Product Description

Overview

The IC693PTM101 is a precision Power Transformer Module (PTM) from the GE Fanuc Series 90-30 family. Engineered to provide an isolated AC voltage reference, it is ideal for powering high-speed counters (HSC) and specialized I/O modules that require dedicated, reliable AC input. This module ensures galvanic isolation and robust performance in industrial control environments.

Technical Specifications

Electrical Characteristics

• Input Voltage: 120 VAC, 50/60 Hz

• Output Voltage: 12 VAC (nominal) isolated

• Power Rating: 1.5 VA

• Input Current: ≤0.2 A

• Isolation: Primary to secondary galvanic isolation

• Backplane Voltage Isolation: 1500 V

Data and Performance

• Resolution: 14-bit measurement (for connected I/O modules)

• Data Processing Rate: 20 ms @ 50 Hz / 16.67 ms @ 60 Hz

• Latency: 15 ms @ 50 Hz / 16.67 ms @ 60 Hz

• Power Consumption: 400 mA @ 5 VDC

Mechanical & Environmental

• Module Dimensions: 3.4 x 14.5 x 1.4 cm

• Weight: ~0.6 kg

• Mounting: Single-slot Series 90-30 baseplate compatible

• Operating Temperature: 0°C to 60°C

• Storage Temperature: -40°C to 85°C

• Humidity: 5% to 95% non-condensing

Interface & Components

• Interface Cable: 1-meter IC693CBL340

• Module Components: Processing board, interface board, cable

Key Features

• Supports single-phase, three-phase, and synchro monitoring modes

• Real-time monitoring for electrical parameter analysis

• Predictive diagnostics including phase detection, voltage presence, and measurement validation

• Seamless integration with Series 90-30 CPUs

• High-speed data handling with low latency for dynamic industrial applications

• Robust EMI/RFI-resistant construction suitable for harsh environments

• Facilitates energy management strategies such as load shedding and demand reduction

Applications

• Power supply for high-speed counters and specialized I/O modules

• Industrial automation systems requiring isolated AC references

• Load monitoring and energy management in production environments

FAQ

Q: Can the IC693PTM101 be used with other PLC series?
A: No, it is designed specifically for Series 90-30 systems. Compatibility with other PLC families is not supported.

Q: What is the replacement option for discontinued IC693PTM101?
A: Ensure any replacement module provides 12 VAC isolated output and matches the slot and backplane requirements of Series 90-30 baseplates. Consult GE Fanuc technical support for alternatives.

Q: Does it support three-phase measurement directly?
A: The module itself provides isolated AC reference. Three-phase measurement capability is realized when connected to compatible I/O modules.
