HIMA 32102 Relay Amplifier – SIL 4 Certified Safety Module

Manufacturer: HIMA
Product No.: 32102
Condition：in Stock
Product Type: Relay Amplifier – SIL 4 Certified Safety Module
Product Origin: Germany
Payment:T/T, Western Union
Weight: 1000g
Shipping port: Shanghai/Yiwu/Shenzhen
Warranty: 12 months

Quantity

HIMA 32102 Relay Amplifier Module

Overview

The HIMA 32102 is a 2-fold relay amplifier module designed for the Planar4 safety platform. It is TÜV-tested according to DIN V 19250 RC 1…7 and certified to SIL 4 (IEC 61508), making it ideal for critical safety tasks such as emergency shutdowns, fire and gas protection, and HIPPS applications.

With two independent relay channels, high switching capacity, and fast response times, the HIMA 32102 ensures maximum operational reliability in demanding industrial environments including oil & gas, chemical, and power generation sectors.

Technical Specifications

Feature	Specification
Model Number	32102
Product Type	2-Fold Relay Amplifier
Relay Channels	2 independent relay outputs
Input Signal Type	Digital control signal
Output Type	Potential-free changeover contacts
Switching Voltage	Up to 250 V AC / DC
Switching Current	Up to 4 A
Switching Capacity	AC: ≤ 1000 VA (cos φ > 0.5) DC: ≤ 120 W @ 30 V, ≤ 40 W @ 250 V
Response Time	Typically < 10 ms
Safety Certification	SIL 4 (IEC 61508), TÜV-tested
Mounting Type	DIN rail or rack-mounted (Planar4 system)
Operating Temperature	−25°C to +60°C
Protection Class	IP20
Country of Origin	Germany
