Honeywell 80360230-001 Input/Output Communication Interface Module

The Honeywell 80360230-001, also cataloged as the 80360230-001 Input/Output Communication Interface Module, operates as a dedicated hardware component for serial communication protocol bridging and data integration within Honeywell TDC 3000 Distributed Control System and Measurex platforms.

Hardware Specifications

4-20 mA HART Loop Protocol & Channel Isolation

Functioning as a dedicated Communications Line Interface (CLI) board, the module executes serial data translation and protocol conversion to link industrial automation field devices with supervisory control nodes. It incorporates robust electrical isolation and signal filtering to withstand harsh plant noise environments and prevent ground loop interference across serial communication lines. The circuitry maintains stable timing parameters and voltage thresholds to guarantee reliable telegram delivery and low-latency data exchange within distributed control loops.

Frequently Asked Questions

Q: Does the 80360230-001 module support hot-swapping inside active TDC 3000 equipment racks?

A: Standard maintenance procedures for legacy TDC 3000 hardware require powering down the respective rack slot or cabinet segment before inserting or removing the CLI board to prevent bus communication disruptions.

Q: What is the primary function of this Communications Line Interface board?

A: The board provides specialized serial communication protocol interfaces to simplify data integration between third-party industrial equipment and legacy Honeywell or Measurex control architectures.

Field Installation Guidelines

• Handle the circuit board using certified electrostatic discharge (ESD) protection equipment, including grounded wrist straps and anti-static storage bags.

• Insert the module smoothly into the designated card slot within the Honeywell system cabinet, ensuring proper edge connector seating against the backplane.

• Secure all mechanical locking tabs or fastening screws, verify incoming 24 VDC power, and check communication status indicators upon startup.
