Honeywell CC-PDIS01 Digital Input SOE Module Experion PKS

Product Description

Overview

The Honeywell CC-PDIS01 is a high-precision Digital Input Sequence of Events (DISOE) module designed for integration with the Experion PKS Series C I/O system. It provides fast, time-stamped capture of 24V DC discrete signals from field devices, enabling accurate post-event diagnostics in critical industrial applications.

This module is ideal for environments where millisecond-level event sequencing is essential, including power generation, chemical processing, and oil and gas emergency shutdown systems.

Product Description

The CC-PDIS01 interfaces directly with 24V DC discrete field signals and communicates with the C300 controller via an I/O Termination Assembly (IOTA). Its main function is to capture the precise timing of digital events, providing critical Sequence of Events (SOE) data for control, monitoring, and safety analysis.

Key Functionalities:

• High-resolution SOE recording: Millisecond-accurate timestamps for event sequencing.

• Redundant-ready design: Supports optional redundancy with compatible IOTA modules (CC-TDIL11).

• On-board excitation: Supplies 24V DC to field contacts directly, reducing cabling complexity.

• Diagnostic features: Detects open or broken wires to maintain data integrity.

Technical Specifications

Applications

• Turbine trips and breaker monitoring in power plants

• Emergency shutdown systems in oil and gas facilities

• Interlock and safety system monitoring in chemical plants

• High-speed event logging in critical process control

FAQ

Q: How many digital inputs does the CC-PDIS01 support?
A: It supports 32 discrete input channels.

Q: What is the time resolution for event capture?
A: Events are captured with 1 millisecond accuracy.

Q: Can this module provide power to field devices?
A: Yes, it can supply 24V DC directly to connected field contacts.

Q: Is redundancy supported?
A: Optional redundancy is available when paired with a compatible IOTA module such as CC-TDIL11.
