Honeywell CC-TPIX11 | 8-Channel High-Speed Pulse Input Module for ExHoneywell CC-TPIX11 | 8-Channel High-Speed Pulse Input Module for Experion® PKS C300perion® PKS C300

Product Description:

The Honeywell CC-TPIX11 is a high-performance Pulse Input Module designed for the Experion® PKS (Process Knowledge System), specifically within the C300 controller family. Part of the Series C I/O platform, this module is engineered for interfacing with high-speed pulse-generating field devices, such as flow meters, speed sensors, and tachometers. It offers the precision and speed required for demanding industrial applications, such as custody transfer and monitoring high-speed rotating equipment.

Unlike typical digital input modules, the CC-TPIX11 supports pulse frequencies up to 100 kHz, making it ideal for applications where real-time pulse counting or frequency measurement is critical. This module can be used to accumulate pulse counts for flow totalization or track high-speed rotating machinery, ensuring reliable and accurate data.

Key Features:

• High-Speed Processing:
  Capable of handling pulse frequencies up to 100 kHz, making it ideal for applications such as high-speed flow measurement and rotating equipment monitoring.

• Flexible Configuration:
  Each of the 8 channels can be independently configured for frequency measurement or pulse totalization, offering flexibility for diverse applications.

• Series C Design:
  Designed with a vertical form factor, ensuring high-density mounting and superior heat dissipation within Experion cabinets, optimizing space and performance.

• Redundancy Support:
  Can be configured in a redundant pair to ensure continuous and reliable monitoring of critical flow or speed loops for high availability.

• Galvanic Isolation:
  Provides robust electrical isolation between field wiring and the C300 controller bus to protect against surges and electromagnetic interference (EMI).

• Conformal Coating:
  Standard conformal coating protects the module in Class G3 environments, offering resistance to corrosion from gases and other harsh conditions.

Technical Specifications:

Installation & Termination:

The CC-TPIX11 module must be installed on a Series C Input/Output Termination Assembly (IOTA). The IOTA provides the physical connection points for the field wiring.

• Common Pairing:

• CC-TPIX11: The electronic pulse input module.

• CC-TPIH01 / CC-TPIH11: The corresponding IOTA (Termination Assembly) used for non-redundant or redundant configurations.

Application Note:

Flow Totalization is one of the most common uses for the CC-TPIX11. The module performs pulse counting locally at the hardware level, ensuring accurate totalization even if the C300 controller is processing at a slower cycle. The total pulse count is then passed to the Experion database, supporting accurate billing and process control.

• Field Tip:
  To minimize the risk of false counts, ensure that the field wiring uses shielded twisted pair (STP) cables. High-speed pulse signals are highly susceptible to electromagnetic interference (EMI) from nearby motors or power cables, which can disrupt accurate signal detection.

Why Choose the Honeywell CC-TPIX11?

• High-Speed and Accuracy:
  Handles pulse frequencies up to 100 kHz, ensuring real-time data processing for critical applications such as flow totalization and speed monitoring.

• Flexible and Configurable:
  Configurable for pulse accumulation or frequency measurement, providing versatility for a wide range of industrial uses.

• Redundancy for High Availability:
  Supports redundant configurations, ensuring continuous operation in critical flow or speed loops.

• Reliable in Harsh Environments:
  Equipped with conformal coating, making it suitable for operation in Class G3 environments with exposure to corrosive gases or other harsh conditions.
