Yokogawa AAI143-S50/ATA4S-00 | 16-Channel Analog Input Module

Product Description

The Yokogawa AAI143-S50/ATA4S-00 is a high-precision 16-channel analog input module designed for seamless integration with CENTUM VP and CENTUM CS 3000 Distributed Control Systems (DCS). It allows secure and reliable acquisition of analog current signals from field transmitters, providing galvanically isolated channels to prevent interference and protect control system integrity.

Engineered for dense I/O applications, the AAI143-S50 is ideal for high-resolution monitoring of process variables such as pressure, flow, temperature, and level, while supporting both 2-wire and 4-wire transmitter configurations.

Key Features

• 16 Individually Isolated Channels: Allows dense signal acquisition without risk of ground loops or cross-channel interference.

• High Accuracy: Typical input accuracy is ±0.1% of full-scale, ensuring precise data for critical control loops.

• Wide Input Range: Accepts 4–20 mA signals with allowable overcurrent up to 24 mA per channel.

• Robust Isolation: Withstand voltage of 1500 VAC between input channels and system bus for one minute, protecting the system from electrical surges.

• Flexible Transmitter Support: Each channel can be configured for 2-wire or 4-wire transmitters, with individual 19–25.5 VDC transmitter power.

• Redundancy Ready: Supports dual-redundant configuration for uninterrupted data acquisition.

• Environmental Durability: Conformal coating (S50 variant) resists corrosive gases and harsh industrial conditions.

• Hot-Swappable Design: Live insertion allows module replacement without powering down the station.

• Self-Diagnostics: Continuous monitoring of internal circuitry and field wiring, with immediate HMI alerts on faults.

Technical Specifications

Application Scenarios

The AAI143-S50 module is suitable for control rooms and field I/O networks where high-density analog signal acquisition is required. Common applications include monitoring pressure, temperature, flow, or level in chemical plants, power stations, and large-scale process industries. Its galvanic isolation and redundancy support ensure uninterrupted process data even under harsh conditions.

FAQ

Q: Can this module be used with HART transmitters?
A: No, the S50/ATA4S-00 variant is for pure analog signals. For HART communication, consider the AAI143-H series.

Q: Is hot-swapping supported?
A: Yes, the module can be replaced while the station is powered, avoiding downtime.

Q: How does the S50 variant differ from other AAI143 models?
A: The S50 includes a protective coating and environmental resistance suitable for harsh industrial environments.

Q: Can it handle dual-redundant configurations?
A: Yes, dual redundancy is supported for continuous operation without data loss.
