The YOKOGAWA AAV144-S00 module provides reliable analog output functionality, supporting 4–20 mA signals for actuator control and process regulation in safety instrumented systems.
Specifications
Model Number: AAV144-S00
Brand: YOKOGAWA
Product Type: Analog Output Module
Output Channels: 4 channels
Signal Type: 4–20 mA DC
Resolution: 16-bit D/A conversion
Accuracy: ±0.1% of full scale
Isolation: Channel-to-channel and system isolation
Power Supply: 24 VDC
Installation: ProSafe-RS base unit compatible
Operating Temperature: -20°C to +60°C
Humidity Range: 5% to 95% RH (non-condensing)
Dimensions: Standard ProSafe-RS module size
Weight: Approx. 300 g
Features
Precise Output Control: Delivers stable 4–20 mA signals for critical operations
High Resolution: 16-bit conversion ensures fine control accuracy
Safety Certified: SIL3 compliance for use in safety instrumented systems
Robust Isolation: Protects against electrical interference and cross-channel noise
Modular Integration: Seamlessly fits into ProSafe-RS architecture
Environmental Resilience: Operates reliably in harsh industrial conditions
Diagnostic Capability: Supports fault detection and system health monitoring
Low Power Consumption: Efficient performance with minimal energy demand
