YOKOGAWA ADV151-P03/D5A00 Digital Input Module 1 Year Warranty

Brand: Yokogawa

Condition: 100% New Original

Payment Terms: T/T

Minimum Order Quantity: 1pc

Product Description: YOKOGAWA ADV151-P03/D5A00 Digital Input Module

The Yokogawa ADV151-P03/D5A00 is a digital input module used in Yokogawa's CENTUM CS 3000 Distributed Control System (DCS). It is designed to receive and process digital on/off signals from various field devices and sensors. This module is compatible with both standard and explosion-proof applications.

Features:

32-channel digital input: It can receive signals from up to 32 different devices simultaneously.
Pushbutton input: It includes additional functionality for pushbutton inputs, such as detecting on/off status and counting button presses.
High-speed response: The module boasts a fast response time of 8 ms or less for status inputs.
Wide input voltage range: It can accept a wide range of input voltages, from 4.1 mA to 30.0 V DC.
Dual redundancy support: It can be configured in a dual redundant configuration for increased system reliability.
ISA Standard G3 compliance (optional): This option ensures the module meets the environmental and performance requirements of the ISA-S75.03 standard.
Temperature range: The module operates within a temperature range of -20 to 70 °C (with the optional ISA G3 compliance).

Technical Specifications:

Number of input channels: 32
Input voltage range: 4.1 mA±20% / channel, 2.5 mA±20% / channel, 30.0 V DC max
Input response time: 8 ms or less (status input)
Minimum ON detection time: 20 ms (pushbutton input)
Maximum ON/OFF cycle: 25 Hz (pushbutton input)
Power consumption: 500 mA (5 V DC)
Weight: 0.3 kg

Competitive Series:

• Yokogawa Centum CS - Centum VP
• Yokogawa Centum XL - micro XL
• Yokogawa FA-M3
• Yokogawa ProSafe-PLC
