Yokogawa ATF9S-00 Pressure Clamp Terminal Block

Description

The Yokogawa ATF9S-00 is a compact 4-port pressure clamp terminal block engineered for Foundation Fieldbus applications. It offers reliable signal connectivity and is optimized for standard wiring environments without surge absorbers. Designed to meet ISA Standard G3, it ensures durability in industrial settings.

Specification

• Model Number: ATF9S-00

• Manufacturer: Yokogawa

• Signal Type: Foundation Fieldbus

• Compatible Module: Yokogawa ALF111

• Port Count: 4 (CH1, CH2, CH3, CH4)

• Connection Type: Pressure clamp (tool-less)

• Dimensions: 35.2 mm × 27.2 mm × 112 mm

• Weight: ≤ 0.10 kg

• Tolerance:

  • ±0.8 mm for dimensions 0.5–120 mm

  • ±1.5 mm for larger tolerances

Key Benefits

• 4-Port Connectivity: Supports CH1 to CH4 for Foundation Fieldbus signals

• ISA G3 Compliance: Enhanced environmental resistance for industrial use

• No Surge Absorber: Ideal for standard Fieldbus wiring setups

• Ultra-Lightweight: Weighs less than 0.10 kg, saving panel space

• Tool-Free Wiring: Pressure clamp terminals simplify installation

• Dedicated Compatibility: Designed for seamless use with Yokogawa ALF111 module
