The ATI3S-S00 is a Yokogawa analog input terminal module designed for accurate signal acquisition in industrial automation systems. It supports multiple input types and integrates seamlessly with control platforms.
Specifications
Model: ATI3S-S00
Manufacturer: Yokogawa
Input Channels: 16 analog input points
Signal Type: Voltage or current input (configurable per channel)
Input Range: ±10 V, 0–10 V, 4–20 mA depending on configuration
Resolution: 16-bit A/D conversion for precise measurement
Isolation: Channel-to-channel and system isolation
Connection Method: Terminal block interface
Mounting: DIN rail or panel-mounted
Operating Temperature: 0°C to 55°C
Storage Temperature: -20°C to 70°C
Weight: Approximately 0.3 kg
Features
High Accuracy: 16-bit resolution ensures reliable analog signal capture
Flexible Input Configuration: Supports both voltage and current signals
Robust Isolation: Prevents interference between channels and system
Compact Design: Saves space in control cabinets
System Compatibility: Works with Yokogawa’s CENTUM VP and ProSafe-RS series
Easy Wiring: Terminal block simplifies installation and maintenance
Industrial Reliability: Built for continuous operation in demanding environments
