Yokogawa LS38-C3S-TI-N-GD Fiber Optic Transceiver Module

Product Overview

The LS38-C3S-TI-N-GD (LS38-C3S-TI-N-GD) is a high-performance, small form-factor pluggable (SFP) optical transceiver engineered for Yokogawa industrial networking and control systems. This module facilitates high-speed data transmission over single-mode fiber (SMF), supporting rates between 1063 and 1250 Mb/s. Utilizing a 1310 nm Fabry-Perot (FP) laser, it is capable of bridging distances up to 10 km. Designed for mission-critical infrastructure, the module operates across an extended industrial temperature range, ensuring network stability in environments subject to thermal extremes.

Technical Specifications

• Module Type SFP (Small Form-Factor Pluggable)

• Model / P/N LS38-C3S-TI-N-GD

• Data Throughput 1063 Mb/s to 1250 Mb/s

• Optical Wavelength 1310 nm

• Fiber Type Single-Mode Fiber (SMF) 9/125 μm

• Maximum Reach 10 km

• Interface LC Duplex Connector

• Transmitter Source Fabry-Perot (FP) Laser Diode

• Receiver Architecture PIN Photodiode

• Optical Output Power -9.5 to -3 dBm

• Receiver Sensitivity -20 dBm (Maximum)

• Optical Link Budget ~10.5 dBm

• Saturation Power -3 dBm

• Input Voltage 3.3 V (Nominal)

• Current Consumption 250 mA (Tx + Rx combined)

• Operating Temperature -40°C to 85°C (Industrial Grade)

• Environmental Standards RoHS Compliant

Network Integration & Durability

The LS38-C3S-TI-N-GD (LS38-C3S-TI-N-GD) is built to meet the rigorous demands of industrial Ethernet and fieldbus communication:

• Hot-Swappable Design Allows for module replacement or upgrades without powering down the host networking equipment.

• Extended Temperature Resilience Unlike commercial-grade SFPs, this unit maintains timing and signal integrity from -40°C to 85°C.

• Low Latency Transmission Optimized for the deterministic data requirements of industrial control loops and PLC synchronization.

• Standardized Form Factor Compatible with a wide range of Yokogawa switches, routers, and controller optical ports.
