The S2BN1D-19030 is a high-performance baseplate module from Yokogawa, designed for ProSafe-RS systems. It supports multiple I/O configurations and ensures stable field signal integration.
Specifications
Manufacturer: Yokogawa
Model: S2BN1D-19030
Mounting: DIN rail or wall mount with M4 × 4 screws
I/O Configuration: Redundant or single module setup
Number of Channels: 16 channels
Field Signal Connection:
Pressure Clamp Terminal (S2BN1D-1)
Spring Clamp Terminal (S2BN1D-2)
Cable Connector (S2BN1D-9)
F-SB Bus: Connected via F-SB Bus Cable (S2KLF10)
System Power Supply: Linked through Power Supply Cable (S2KPB10)
Grounding: M3 screw terminal
Withstanding Voltage: 1500 V AC for 1 minute, 42 V DC continuous
Insulation Resistance: ≥100 MΩ at 500 V DC
Weight: Approx. 1.4 kg
Features
Flexible Mounting: Supports both DIN rail and wall installation
Modular Design: Compatible with various I/O terminal types
High Isolation: Optical and electrical separation for safety
Reliable Power Distribution: Stable system power routing via dedicated cables
Robust Build: Engineered for industrial environments
Efficient Wiring: Quick-connect terminals simplify field integration
System Compatibility: Seamlessly integrates with ProSafe-RS architecture
